surface mounted luminaire - reflector - rectangular - RAL9018-grey
housing of fibreglass-reinforced polyester
polycarbonate cover
polyurethane seal
quick release latches of stainless steel
lighting (anti-panic or escape route)
self-test/communication: EST+ extensive self-test
lumenoutput in emergency: 840 lm

Distance tables: ceiling mounted

In m for 0.5 lux and 840 lm
habcd
2.8m9.122.55.513.1
3.0m9.423.25.713.6
3.5m10.024.76.114.7
4.0m10.526.06.415.7
4.5m11.027.36.716.5
5.0m11.428.57.017.2
5.5m11.829.67.217.9
6.0m12.030.57.318.6
6.5m12.231.47.519.2
7.0m12.332.27.519.7
7.5m12.332.97.620.1
8.0m12.433.57.620.4
8.5m12.434.07.720.7
9.0m12.434.37.721.0
9.5m12.434.57.621.2
In m for 1 lux and 840 lm
habcd
2.8m7.418.24.510.9
3.0m7.618.84.611.3
3.5m8.020.04.912.1
4.0m8.421.05.112.8
4.5m8.622.05.213.4
5.0m8.722.85.313.9
5.5m8.723.55.414.3
6.0m8.824.05.414.6
6.5m8.824.35.414.9
7.0m8.824.55.315.1
7.5m8.724.65.215.2
8.0m8.624.75.115.3
8.5m8.524.84.815.3
9.0m8.324.84.615.3
9.5m8.024.84.215.2

Distance tables: wall mounted

In m for 0.5 lux and 840 lm
habcd
1.5m6.917.44.510.5
2.0m7.519.05.112.0
2.5m7.920.25.613.2
3.0m8.221.16.014.3
3.5m8.321.96.315.2
4.0m8.522.56.616.0
4.5m- 16.66.816.7
5.0m- 12.17.017.3
5.5m- - 7.217.8
6.0m- - 7.318.3
6.5m- - 7.418.8
7.0m- - 7.419.2
7.5m- - 7.419.5
8.0m- - 7.419.8
8.5m- - 7.320.1
In m for 1 lux and 840 lm
habcd
1.5m5.513.83.88.9
2.0m5.814.94.310.2
2.5m6.015.74.711.2
3.0m6.116.35.012.0
3.5m6.116.75.212.6
4.0m- 9.75.313.1
4.5m- - 5.413.6
5.0m- - 5.414.0
5.5m- - 5.414.3
6.0m- - 5.414.5
6.5m- - 5.214.7
7.0m- - 5.014.8
7.5m- - 4.814.9
8.0m- - 4.514.8
8.5m- - 4.214.7
