surface mounted luminaire - reflector - rectangular - RAL9018-grey
housing of fibreglass-reinforced polyester
polycarbonate cover
polyurethane seal
quick release latches of stainless steel
lighting (anti-panic or escape route) - inhibiting mode
self-test/communication: EST+ extensive self-test
lumenoutput in emergency: 470 lm

Distance tables: ceiling mounted

In m for 0.5 lux and 470 lm
habcd
2.8m7.718.94.611.3
3.0m7.919.44.811.7
3.5m8.320.75.112.5
4.0m8.721.85.313.2
4.5m9.022.85.513.9
5.0m9.123.75.614.4
5.5m9.224.45.714.9
6.0m9.325.15.715.3
6.5m9.325.55.715.6
7.0m9.325.75.715.8
7.5m9.325.95.616.0
8.0m9.226.15.516.1
8.5m9.126.25.316.1
9.0m9.026.25.116.2
9.5m8.826.34.816.2
In m for 1 lux and 470 lm
habcd
2.8m6.115.33.79.2
3.0m6.215.73.89.5
3.5m6.416.63.910.1
4.0m6.517.44.010.6
4.5m6.617.94.010.9
5.0m6.618.24.011.2
5.5m6.618.43.911.3
6.0m6.518.53.811.4
6.5m6.318.63.611.4
7.0m6.118.63.211.4
7.5m5.718.52.811.2
8.0m5.218.42.211.0
8.5m4.318.21.110.6
9.0m- 17.9- 10.2
9.5m- 15.8- 9.6

Distance tables: wall mounted

In m for 0.5 lux and 470 lm
habcd
1.5m5.714.43.99.2
2.0m6.115.54.410.4
2.5m6.316.44.811.5
3.0m6.417.05.112.3
3.5m6.517.55.313.0
4.0m- 11.25.513.6
4.5m- - 5.614.0
5.0m- - 5.714.5
5.5m- - 5.714.8
6.0m- - 5.715.1
6.5m- - 5.615.4
7.0m- - 5.515.5
7.5m- - 5.315.6
8.0m- - 5.015.7
8.5m- - 4.815.6
In m for 1 lux and 470 lm
habcd
1.5m4.511.33.37.8
2.0m4.712.13.78.8
2.5m4.712.64.09.6
3.0m4.712.84.110.2
3.5m- 7.14.210.6
4.0m- - 4.211.0
4.5m- - 4.211.2
5.0m- - 4.011.4
5.5m- - 3.811.4
6.0m- - 3.511.4
6.5m- - 3.211.2
7.0m- - 2.810.9
7.5m- - 2.310.5
8.0m- - 1.110.0
8.5m- - - 9.5
