surface mounted luminaire - reflector - rectangular - RAL9018-grey
housing of fibreglass-reinforced polyester
polycarbonate cover
polyurethane seal
quick release latches of stainless steel
lighting (anti-panic or escape route) - for exterior use (t >= -15°C)
self-test/communication: ESM-RF ETAP Safety Manager - wireless
lumenoutput in emergency: 220 lm

Distance tables: ceiling mounted

In m for 0.5 lux and 270 lm
habcd
2.8m6.616.34.09.9
3.0m6.716.84.110.1
3.5m7.017.84.310.8
4.0m7.218.74.411.4
4.5m7.319.44.511.8
5.0m7.320.04.512.2
5.5m7.320.34.512.4
6.0m7.320.44.412.6
6.5m7.220.64.312.7
7.0m7.120.74.112.7
7.5m6.920.73.812.7
8.0m6.620.73.412.6
8.5m6.220.63.012.4
9.0m5.720.52.312.2
9.5m4.720.31.111.8
In m for 1 lux and 270 lm
habcd
2.8m5.113.13.18.0
3.0m5.113.43.18.2
3.5m5.214.03.28.6
4.0m5.214.33.28.8
4.5m5.114.53.18.9
5.0m5.014.62.99.0
5.5m4.814.62.69.0
6.0m4.414.62.18.8
6.5m3.814.41.48.5
7.0m- 14.2- 8.1
7.5m- 12.5- 7.6
8.0m- 9.9- 6.0
8.5m- 8.3- 4.7
9.0m- 6.9- 3.4
9.5m- 5.1- 1.6

Distance tables: wall mounted

In m for 0.5 lux and 270 lm
habcd
1.5m4.812.23.58.2
2.0m5.113.13.99.3
2.5m5.213.74.210.2
3.0m5.214.14.410.9
3.5m- 9.44.611.4
4.0m- - 4.611.8
4.5m- - 4.612.1
5.0m- - 4.612.3
5.5m- - 4.412.5
6.0m- - 4.212.6
6.5m- - 4.012.6
7.0m- - 3.712.4
7.5m- - 3.312.2
8.0m- - 2.911.9
8.5m- - 2.211.5
In m for 1 lux and 270 lm
habcd
1.5m3.79.62.97.0
2.0m3.810.13.27.8
2.5m3.810.33.48.4
3.0m- 6.13.58.8
3.5m- - 3.49.1
4.0m- - 3.39.2
4.5m- - 3.09.2
5.0m- - 2.79.1
5.5m- - 2.48.9
6.0m- - 1.88.4
6.5m- - - 7.9
7.0m- - - 7.3
7.5m- - - 5.7
8.0m- - - 4.3
8.5m- - - 3.0
