surface mounted / recessed luminaire - opal diffuser - rectangular - RAL9018-grey
Housing in lacquered aluminium with linear lens, end caps in glassfibre-reinforced PBT
lighting (anti-panic or escape route)
self-test/communication: EST+ extensive self-test
lumenoutput in emergency: 580 lm

Distance tables: ceiling mounted

In m for 0.5 lux and 580 lm
habcd
2.8m6.215.35.713.4
3.0m6.415.85.913.9
3.5m6.816.76.315.1
4.0m7.117.66.816.2
4.5m7.418.57.117.2
5.0m7.719.37.518.1
5.5m8.020.07.819.0
6.0m8.320.68.019.7
6.5m8.521.38.320.5
7.0m8.721.98.521.1
7.5m8.922.48.721.7
8.0m9.022.98.822.3
8.5m9.223.49.022.8
9.0m9.323.99.123.3
9.5m9.424.39.223.7
In m for 1 lux and 580 lm
habcd
2.8m5.012.34.711.3
3.0m5.112.74.911.7
3.5m5.413.55.212.7
4.0m5.714.25.513.5
4.5m5.914.95.814.3
5.0m6.115.46.014.9
5.5m6.316.06.215.5
6.0m6.516.56.316.1
6.5m6.616.96.416.5
7.0m6.717.46.517.0
7.5m6.717.76.517.3
8.0m6.718.06.517.6
8.5m6.718.36.517.9
9.0m6.618.56.418.1
9.5m6.618.76.318.3

Distance tables: wall mounted

In m for 0.5 lux and 580 lm
habcd
1.5m4.511.63.68.7
2.0m4.812.43.99.4
2.5m4.913.04.110.0
3.0m4.913.34.210.5
3.5m4.813.44.310.9
4.0m4.513.44.311.2
4.5m- 13.24.211.4
5.0m- 7.94.211.5
5.5m- - 4.011.6
6.0m- - 3.811.6
6.5m- - 3.511.5
7.0m- - 3.111.3
7.5m- - 2.711.0
8.0m- - 1.910.7
8.5m- - - 10.3
In m for 1 lux and 580 lm
habcd
1.5m3.59.13.07.2
2.0m3.69.53.17.8
2.5m3.59.83.28.1
3.0m3.39.73.28.4
3.5m2.89.53.18.5
4.0m- 6.72.98.5
4.5m- - 2.78.5
5.0m- - 2.48.3
5.5m- - 1.88.0
6.0m- - 0.87.6
6.5m- - - 7.0
7.0m- - - 5.6
7.5m- - - 4.2
8.0m- - - 2.8
8.5m- - - -
